| Camera |
Uho-P1H-M3F4D |
| Sensor |
1/2.8″ progressive scan, 3.0 megapixel, CMOS |
| Min. Illumination |
Colour:0.005 lux (F1.6,AGC ON) 0 lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, shutter time: 1s ~ 1/100000s |
| WDR |
DWDR |
| S/N |
>52 dB |
| Lens |
| Lens type |
[email protected] |
| Digital Zoom |
4 |
| Iris |
Fixed |
| Field of View (H) |
91.2° |
| Field of View (V) |
47.9° |
| Field of View (D) |
95.9° |
| DORI |
| DORI Distance |
Lens (mm) |
Detect (m) |
Observe (m) |
Recognize (m) |
Identify (m) |
| 4mm |
72.0 (236.2ft) |
28.8 (94.5ft) |
14.4 (47.2ft) |
7.2 (23.6ft) |
| Illuminator |
| IR Range |
Up to 30m (98ft) |
| Warm Light Range |
Up to 10m (33ft) |
| Wavelength |
850nm |
| IR On/Off Control |
Auto/Manual |
| Video |
| Video Compression |
Ultra 265, H.265, H.264 |
| Frame Rate |
Main Stream: 3MP (2304*1296), Max 20fps; 2MP (1920*1080), Max 25fps; 720P (1280*720), Max 25fps; Sub Stream: 640*360,Max 25fps; 2CIF(704*288), Max 25fps; CIF(352*288), Max 25fps; |
| Video Bit Rate |
128 Kbps~2048 Kbps |
| ROI |
Up to 8 areas |
| Video Stream |
Dual streams |
| OSD |
Up to 2 OSDs |
| Privacy Mask |
Support(Only NVR) |
| Image |
| White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction |
2D/3D DNR |
| Smart IR |
Support |
| Flip |
Normal/Flip Vertical/Flip Horizontal/180° |
| HLC |
N/A |
| BLC |
N/A |
| Defog |
Digital Defog |
| Events |
| Basic Detection |
Motion detection, Ultra motion detection, Audio detection |
| Auto tracking |
Support |
| General Function |
IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication |
| Audio |
| Audio Compression |
G.711U,G.711A |
| Audio Bitrate |
64 Kbps |
| Two-way Audio |
Support |
| Suppression |
Support |
| Sampling Rate |
8 kHz |
| Storage |
| Edge Storage |
Micro SD, up to 512 GB |
| Network Storage |
ANR |
| Network |
| Wi-Fi |
2.4G Wi-Fi (IEEE802.11b/g/n/ax), built-in antenna |
| Protocols |
IPv4, TCP, UDP, DHCP, RTSP, DNS, DDNS, NTP, HTTP |
| Compatible Integration |
API |
| Client |
Uniarch Client Uniarch APP |
| Web Browser |
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above |
| Wi-Fi |
| Wireless Standards |
IEEE802.11b/g/n/ax |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth |
20/40 MHz Support |
| Modulation Mode |
802.11b: CCK 802.11g/n: OFDM 802.11ax: OFDMA |
| Security |
64/128-bit WEP, WPA-PSK/WPA2-PSK |
| Transmit Power |
802.11b: 17±1.5dBm @11Mbps 802.11g: 16±1.5dBm @ 54Mbps 802.11n: 16±1.5dBm @MCS7 802.11ax: 16±1.5dBm @MCS9 |
| Receive Sensitivity |
802.11b: -76dBm @11Mbps (Typical) 802.11g: -65dBm @54Mbps (Typical) 802.11n: -61dBm @MCS7,HT40(Typical) 802.11ax: -54dBm @MCS9,HE40(Typical) |
| Transmission Rate |
802.11b: 11Mbps 802.11g: 54Mbps 802.11n: up to 150Mbps 802.11ax: up to 270Mbps |
| Pan & Tilt |
| Pan Range |
0° ~ 345° |
| Pan Speed |
1°/s ~ 40°/s |
| Preset speed: 40°/s |
| Tilt Range |
0° ~ 90° |
| Tilt Speed |
1°/s ~ 30°/s |
| Preset speed: 30°/s |
| Number of Presets |
20 |
| Interface |
| Built-in Mic |
Support |
| Built-in Speaker |
Support |
| Wi-Fi |
Support |
| Network |
1 * RJ45 10M/100M Base-TX Ethernet |
| Certifications |
| EMC |
CE EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 50130) FCC (FCC 47 CFR part15 B) |
| RF |
FCC ID (FCC CFR 47 part15 C) CE RED (EN 301 489-1, EN 301 489-17, EN 300 328, EN 62311) |
| Safety |
CE LVD (EN 62368-1) |
| Environment |
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU) |
| Protection |
IP66 (IEC 60529) |
| General |
| Power |
DC 12V ± 25% |
| Power consumption: Max 11.0W |
| Power Interface |
Ø 5.5mm coaxial power plug |
| Dimensions (Ø x H) |
Φ118mm*118mm*199mm (Φ4.6”x 4.6”x 7.8”) |
| Weight |
0.53kg (1.17lb) |
| Working Environment |
-30°C ~ 60°C (-22°F to 140°F), Humidity:≤95% RH(non-condensing) |
| Surge Protection |
4KV |
| Reset Button |
Support |
| LED indicator |
1,green |
